A bundle including the Still Spirits Create+ Boiler 25 L, Create+ T500 Stainless Steel Condenser and Create+ Botanical Sight Glass .Combine to create an all-in-one reflux system designed to streamline the distillation process while delivering exceptional results.

It’s 2″ tri-clamp connection allows for it to be connected to 2″ tri-clamp accessories, so your customers have the option to experiment with different setups and attachments.This all-in-one apparatus eliminates the need for separate components, simplifying the distillation process without compromising on performance. However, its 2″ tri-clamp connection allows for it to be connected to 2″ tri-clamp accessories, so your customers have the option to experiment with different setups and attachments. The T500 features a cutting-edge design that incorporates pre-packed copper and stainless-steel saddles. This innovative amalgamation ensures optimal vapour reflux, facilitating the production of superior-quality distillate. Ideal for both novice and experienced distillers, the T500 redefines convenience in home distillation, delivering unmatched results with a seamless blend of form and function.

With a maximum capacity of 25 litres, the Boiler 25 L features dual element control switches, providing more control during distillation.

Features:

• All-in-one reflux column and condenser + boiler
• For intermediate-advanced distilling
• Suitable for distilling water and alcohol
• T500 constructed from high-quality T2-grade copper with stainless steel tri-clamp ferrules
• Designed in New Zealand
• Pre-packed with copper (105 g) and stainless steel saddles (485 g)
• 2″ tri-clamp connections
• Integrated thermowell in the column head for accurate vapour temperature readings
• Beeping alarm thermometer with adjustable high/low temperature alerts
• Removable cold finger cooling coil and detachable product condenser
• Food-grade silicone seals
• Saves up to 30% water compared to the original T500 (depending on usage)
• Dual boiler element control switches provide more control during distillation – when both switches are in the ON position, the element will be supplied full power of 2200W. When one switch is in the OFF position, it will only consume 1100W of power.
• Boil dry reset
• Thermal cut out fuse
• Waste discharge tap with a stainless-steel ball valve
• Boiler lid with 48 mm opening
• 25 L Boiler capacity

Whats Included:

• Create+ T500 Stainless Steel Column & Condenser
• 2 x Create+ 2″ Tri-Clamps
• Copper and Stainless Steel Saddles (Pre-Packed)
• Create+ Beeping Alarm Thermometer with 2″ Mounting Bracket
• 2x Cooling Water Tubes
• Ceramic Boil Enhancers
• Tap Adapter Flow Controller with Kitchen and Garden Tap Adapters
• Still Spirits Boiler 25 L
• DN40 Nut
• Sieved Gasket
• Silicone Gasket
• 2″ Tri-Clamp to DN40 Threaded Adapter
• Instructions

Specifications:

T500 Stainless Steel Condenser:

• Dimensions: H 69 cm x W 8.5 cm x D 16 cm
• Weight: 2.3-2.99 kg
• Warranty: 3 years
• Ease of Use: Intermediate
• Average water use during distillation: You will use approx. 200 L (54 US Gal) per 25 L distillation.*
• Yield: 8 L (2.1 US Gal) of 40% ABV alcohol per 25 L (6.6 US Gal) wash (based on using the standard recipe of 6 kg (13.2 lb) of sugar**
• Purity: Distills at up to 93% ABV (186 US proof) before diluting to 40% ABV (80 US proof)**

* When used with the Create+ Water Flow Regulator.

**Per 25 L (6.6 US Gal) Turbo Classic 8 Production pack wash using the Create+ Boiler 25 L and T500 Reflux Condenser.
